• Provides discrete dusk to dawn lighting control
• Ultra-precise switching
• Saves energy and costs, providing dusk to dawn illumination when required

• 10mm turret diameter is 50% smaller than regular miniature photocells
• Ideal for modern compact lanterns with limited installation space

Sensor:

Sensor: Filtered Photodiode

Switching Technology:

Switching Technology: Electronic EM Relay Load Switching

Switching Regime in Lux and Time:

70 Lux / 35 Lux: Yes

55 Lux / 28 Lux: Yes

35 Lux / 18 Lux: Yes

Switching Ratio: 1:0.5

Switching Delay: 10 seconds

Load:

Maximum load for LED lighting: 125 Watts

Maximum load for High Pressure Sodium: 250 Watts

Maximum load for Metal Halide: 250 Watts

Maximum load for GLS or incandescent: 600 Watts

Supply and Consumption:

Voltage: 198-264

Surge Suppression: 20 Joules

Frequency: 50Hz

Consumption in Watts: <0.25

UMSUG Charge Code: 94 0001 1000 100

Operating Temperature:

Min / Max operating ambient temp range: -20 /+75°C

IP Rating: IP65 when installed

Warranty: 6 years

Compliance Standards:

BS5972, BS EN IEC 55015, BS EN 60529, BS EN IEC 6100-3-2, EN 6100-3-3, BS EN IEC 61000-4-2, BS EN IEC 61000-4-3, BS EN 61000-4-4, BS EN 61000-4-5, BS EN 61000-4-6, BS EN IEC 61000-4-11, BS EN 61547
